Screen parameters | ||||||||
Size | 65" | 75" | 86" | 100" | ||||
Type | ADS | |||||||
Response time | 8 ms | |||||||
Display ratio | 16:9 | |||||||
Display size (mm) | 1428×804 | 1650×928 | 1895×1066 | 2159×1214 | ||||
Resolution | 3840(H)×2160(V) | |||||||
Pixel pitch (mm) | 0.372×0.372 | 0.429×0.429 | 0.4935×0. 4935 | 0.5622×0. 5622 | ||||
Refresh rate | 60Hz | 60Hz | 60Hz | 120Hz | ||||
Color brightness | 1.07B(10bit) | |||||||
Color gamut | 72% | |||||||
Contrast ratio | 4000:1 | 1200:1 | 1200:1 | 1200:1 | ||||
Viewing angle | 178°(H/V) | |||||||
Backlight | DLED | |||||||
Screen brightness | 350cd/m2 | 350cd/m2 | 350cd/m2 | 350cd/m2 | ||||
Life time | ≥30000h |
Touch writing system | ||||||||
Principle of Recognition | Infrared recognition | |||||||
Touch points | 20 touch | |||||||
Smallest identifier | 2mm | |||||||
Input method | Fingers, touch pens and other opaque objects | |||||||
Response time | <10 ms | |||||||
Touch accuracy | ±1mm (more than 90% touch area) | |||||||
Writing height | 3mm | |||||||
Output coordinates | 32767 (W) ×32767(D) | |||||||
Writing display | Two colors writing |
Built-in system | ||||||||
Motherboard solution | MSD8386 | |||||||
System version | Android 8.0 | |||||||
CPU | Dual core A73 + dual core A53 max1.5GHz | |||||||
GPU | G51MP | |||||||
RAM | 4GB | |||||||
ROM | 32GB |
Interface | ||||||||||
HDMI in | 3 | USB 2.0 | 3 | Touch | 2 | |||||
HDMI out | 1 | USB 3.0 | 3 | VGA in | 1 | |||||
Audio in | 1 | SPDIF | 1 | RS232 | 1 | |||||
Audio out | 1 | RJ45 in | 1 |
Wifi | ||
Version | 802.11 a/b/g/n/ac | |
Operating frequency | 2.4GHz/5GHz | |
Operating distance | 0~12m | |
RAM | 4GB | |
Remark | Realize this function through the wireless module SI02 |
Power | ||||||||
Size | 65" | 75" | 86" | 100" | ||||
Power input 100-240V~50/60Hz | 2.5A | 3.0A | 5.0A | 7.5A | ||||
Power consumption | 250W | 300W | 500W | 750W | ||||
Standby power consumption | ≤0.5W |
Environmental factory | ||
Operating Temperature | 0℃~40℃ | |
Operating humidity | 10%~90%RH | |
Storage temperature | -20℃~60℃ | |
Storage humidity | 10%~90%RH | |
Altitude | ≤5000m |
PC system (optional) | ||||||||
PC Model | I3 / I5 | |||||||
PC Type | Ultra-thin pluggable Intel Core series modular computer | |||||||
CPU Configuration 1 | i5,DDR4 8GB,M.2 solid state drive 128GB (SSD) | |||||||
Configuration 2 | i7,DDR4 16GB,M.2 solid state drive 256GB (SSD) | |||||||
Graphics | Integrated Intel® HD Graphics | |||||||
Sound card | Integrated HD stereo sound card | |||||||
Built-in system | Windows 7/10 Enterprise Edition |
HDMI output | 1 | USB 2.0 | 2 |
USB 3.0 | 2 | Microphone input | 1 |
Audio out | 1 | PC interface | 120 pins |
Size | 55" | 65" | 75" | 86" | 100" |
Display size (inch/mm) | 1210×680 | 1428×804 | 1650×928 | 1895×1066 | 2159×1214 |
Overall size/Weight W×D×H(mm)/kg | 1262×782×85 /26 | 1489×906×89 /37.5 | 1710×1029×89 /52.3 | 1957×1169×90 /69.8 | 2245×1323×90 /102 |
Packing size/Weight W×D×H(mm)/kg | 1428×220×878 /36 | 1656×204×1050 /49.8 | 1886×210×1196 /66.2 | 2134×210×1334 /89.4 | 2483×376×1493 /136 |
QTY of containers(pcs) 20'GP/40'GP/40'HQ | 102/236/254 | 79/183/197 | 59/137/148 | 53/123/133 | 20/47/50 |
